Century C346, 7-P56AF22A01-01, Three Phase and 13 similar items

The Century C346 (7-P56AF22A01-01) Three-Phase Totally Enclosed Auger Drive Motor is a heavy-duty 1/2 HP, 1800 RPM motor engineered for demanding agricultural feed delivery systems. Built with a TEFC enclosure, 56N frame, and torque switch/governor, this motor delivers the high starting torque required for reliable auger startup under load. Its double-sealed ball bearings, manual reset thermal protector, and reversible rotation ensure long-lasting durability and safe operation in dusty, high-moisture farm environments. UL recognized and CSA certified, it is a trusted, farm-duty solution. Key Features 1/2 HP, 1800 RPM auger drive motor High starting torque for tough agricultural loads Totally Enclosed Fan Cooled (TEFC) for protection in dirty or dusty areas Manual reset thermal protector for safety Double-sealed ball bearings for extended life Torque switch and governor for controlled auger operation Reversible rotation for flexible installation UL recognized CSA certified 1.0 Service Factor 56N frame with secure mounting Specifications Part Numbers: C346, 7-P56AF22A01-01 Horsepower: 1/2 HP RPM: 1800 Voltage: 208?230/460V, Three Phase Frame: 56N Frame Enclosure: TEFC (Totally Enclosed Fan Cooled) Bearings: Double-Sealed Ball Bearings Protection: Manual Reset Thermal Protector Motor Type: Capacitor-assisted start (agricultural duty) Service Factor: 1.0 S.F. Rotation: Reversible Applications Designed specifically for: Direct-drive auger feeding systems Poultry feed delivery Swine feed delivery Agricultural conveyor/auger systems Why Choose This Item The Century C346 is an excellent choice for agricultural auger systems requiring high torque, TEFC durability, and reliable long-term operation. With sealed bearings, torque control, and thermal protection, this motor withstands harsh farm conditions while providing consistent, dependable performance for livestock feeding operations.
