Commscope Andrew Passive Drive 2 Way Low and similar items

Commscope ANDREW PASSIVE DRIVE 2 WAY LOW POWER SPLITTER S-2 CPUSE-L-N BRAND New The CommScope / Andrew S-2-CPUSE-L-N is a 2-way low-power, low-PIM RF splitter designed for Distributed Antenna Systems (DAS), cellular infrastructure, and in-building wireless networks. Key specifications Model: S-2-CPUSE-L-N Type: 2-way passive RF splitter Frequency range: 698?2700 MHz Impedance: 50 ? Connectors: N-type female Split loss: 3.0 dB (nominal) Insertion (dissipative) loss: 0.3 dB (698?2500 MHz), 0.4 dB (2500?2700 MHz) Isolation: 20 dB VSWR: 1.2:1 Return loss: 20.8 dB Average power (splitting): 50 W Peak power: 1 kW Power rating (combining): 0.5 W 3rd-order PIM: ?130 dBc (two +43 dBm carriers) Environmental rating: IP65, suitable for indoor and outdoor installations Operating temperature: ?25 C to +85 C Applications The S-2-CPUSE-L-N is commonly used in: Cellular Distributed Antenna Systems (DAS) LTE and 5G in-building coverage Public safety radio systems Small-cell and repeater installations RF signal distribution where one input must be divided equally into two outputs SHELF: PS-7 SA
