Haohan Firefly Vtol 2 Hand Launched and 12 similar items

Function and Performance Main Parameters Installation Time: ?1 minute Flight Speed: 10m/s - 27.7m/s Standard Takeoff Weight: 1100g Cruising Speed: 15.8m/s Overall Dimensions: 1080690376mm Maximum Endurance Time: 70min (4S1P 21700) 160min (4S2P 21700) Maximum Range: 60km (4S1P 21700) 150km (4S2P 21700) Maximum Operating Altitude: 4000m Maximum Takeoff Weight: ?2Kg Remote Control Range: 10km (In open or spacious condition) Packaging Box Dimensions: 583453256mm HAOHAN-X7 FC Specifications Main Processor: STM32H743 Processor Frequency: 480 MHz Flash Memory: 2 MB RAM: 1 MB IMU (Inertial Measurement Unit): ICM-42688-P and BMI088 (dual IMU redundancy) Electronic Compass: IST-8310 Barometer: ICP-20100 Built-in Black Box Storage: 2 GB Serial Ports (UART): 5 channels I2C Interface: 1 channel CAN Bus: 2 channels ADC Inputs: 2 channels, supporting up to 3.3V and 6.6V respectively PWM Outputs: 12 channels ESC DShot Support: Yes, Bidirectional BDshot on P1?P4 RC Input: 1 SBUS channel via 3-pin interface Safety Switch: 1 channel Power Supply: 12V 5A 2 5V 5A 2 CAN Bus Expansion Edition Main Processor: STM32L431 Serial Ports (UART): 2 channels I2C Interface: 1 channel ESC DShot Support: Supported, test points reserved for up to 4 motors PWM Outputs: 11 channels LED Lighting Control: 2 channels Power Input: 12V + 5V Servo Power Output: 6V / 5A Dimensions and Weight X7 Flight Controller Dimensions: 99 64.5 17.5 mm X7 Flight Controller Weight: 55 g (including XT60 connector) CAN Bus Expansion Board Dimensions: 51.5 39.5 11 mm CAN Bus Expansion Board Weight: 10.5 g Core Features Modular Design: Reliable quick-release structures in multiple components, reducing assembly time to within 1 minute. Aerodynamic Design: Optimized for efficient flight and superior stall resistance through high-lift airfoil profiles, wing twist, and elliptical lift distribution. Intelligence Safety: Equipped with an Ardupilot-based flight controller offering multiple flight modes including take-off, stabilize, auto return-to-home, loiter, etc. 3-Axis Gimbal HD Video Transmission: Supports 1080P visuals and 2K 30FPS card recording. Screen-equipped Controller: 5.5-inch high-definition display with a brightness of up to 1000 nits, ensuring clear visibility under direct sunlight. Development Journey Conceptual Design to Product Definition: 2022.8 - 2023.5 First Prototype and Maiden Flight: 2023.5 - 2023.8 Flight Platform Optimization: 2023.8 - 2023.12 Detail Optimization and Design for Manufacturing: 2023.12 - 2024.1 Conclusion FireFly VTOL Fixed-Wing FPV Drone offers a unique combination of efficiency, portability, and advanced features. With its modular design, aerodynamic efficiency, and intelligent flight control, it is well-suited for various applications including law enforcement patrols, reconnaissance, and emergency rescue missions.
